ISH 2025

Imbat Takes the Stage at ISH 2025 with Next-Generation Solutions

Imbat will showcase its eco-friendly, high-efficiency, and smart systems at ISH 2025 in Frankfurt. With the Perseus Rooftop, In-Row data center cooling solution, and next-generation chiller units, the company will once again demonstrate its innovation leadership in the industry.

News Link 1

News Link 2

Imbat to Showcase Next-Generation HVAC Solutions at ISH 2025

With 34 years of experience in the HVAC industry, Imbat will take part in ISH 2025, one of the world’s largest trade fairs for HVAC and water technologies. The event will be held in Frankfurt, Germany, from March 17–21, 2025, where Imbat will present its environmentally friendly and high-efficiency climate control solutions.

At ISH 2025, Imbat will welcome visitors at Hall 8, Stand H71, showcasing its new-generation Perseus Rooftop Series, In-Row cooling solution developed for data centers, and a chiller unit using R454-B refrigerant.

Products to Be Introduced by Imbat at ISH 2025

Perseus Rooftop Series
One of Imbat’s latest innovations, the Perseus Rooftop Series, stands out with its energy efficiency and environmentally friendly features. These next-generation rooftop systems achieve up to 78% lower carbon emissions with R454B refrigerant, while asymmetric compressor technology adapts to variable load conditions, delivering up to 30% energy savings.

The double-skin casing with 50 mm, 70 kg/m³ rock wool insulation ensures superior thermal and acoustic insulation, while enhancing fire safety and mechanical durability. EC plug fans and electronic expansion valves minimize energy consumption and provide maximum efficiency with high SEER and SCOP values. Free cooling and free heating functions continuously monitor outdoor conditions to provide natural cooling and heating, reducing operating costs and ensuring long-term savings. With its eco-friendly design, advanced automation infrastructure, and high performance, the Perseus Rooftop Series sets a new benchmark in climate control systems.

Fully compatible with building management systems and equipped with free cooling and free heating features, the product offers a sustainable solution for commercial and industrial applications.

In-Row Data Center Cooling Solution
Imbat’s In-Row Cooling Unit provides temperature and humidity control in data centers through direct rack-level cooling. With high-efficiency fan systems that reduce energy consumption, the solution ensures uninterrupted and reliable cooling in critical infrastructures, enhancing operational efficiency.

High-Efficiency Chiller Units
At ISH 2025, Imbat will also introduce its high-efficiency chiller units. Compliant with global energy regulations, these systems stand out with low carbon footprints, innovative design, and environmentally friendly refrigerants.

The chiller unit to be exhibited at the fair will also provide key insights into the new chiller series planned for development in 2025. Supported by Imbat’s strong R&D infrastructure, this next-generation solution—designed to meet both current needs and future expectations—aims to redefine energy efficiency and sustainability standards in the sector.

Imbat to Meet Industry Professionals at ISH 2025

Following its presence at major exhibitions such as MCE Milan and Chillventa with its “Engineering is Art” concept, Imbat will continue to present its distinctive design approach that merges engineering and art. Aiming to further strengthen its position in global markets with high-engineering solutions, the company will once again highlight its innovative role in the HVAC sector through sustainable and high-performance products.

Industry professionals will have the opportunity to closely examine Imbat’s latest innovations and meet company representatives at ISH 2025, Hall 8, Stand H71, between March 17–21, 2025.
